New Rugged Book R30 One Page Spec

• Sunlight-viewable
• Full Magnesium Alloy Case with Handle
• 8-hour Battery Life

CZC presents the New Rugged® R30, the reliable laptop offering theworld’s most rugged design. With drop-shock protection and a MIL-STD-810G&GJBcertification, it’s the undisputed leader in the fully rugged category. Combine new generations of delivering rugged performance.

SOFTWARE

• Windows® XP Professional Windows® 7 Professional
• CZC New Rugged Utilities, Recovery Partition

DURABILITY

• MIL-STD-810G/GJB (6' drop, shock, vibration, rain, dust, sand, altitude, freeze/thaw, high/low temperature, temperature shock, humidity, explosive atmosphere)
• IP65 certified sealed all-weather design
• Full magnesium alloy case with handle
• Reinforced locking port covers

CPU

• Intel® Core™ i7-3517UE Processor
• 1.7GHz with Turbo Boost up to 2.8GHz
• 4MB cache

STORAGE & MEMORY

• 4GB DDR3L SDRAM Memory Down
• 128GB solid state drives (SSD)

DISPLAY

• 13.3" sunlight-viewable LED 1280 x 800, 500 nit
• HD Graphics 4000
• 13.3" LCD Protector Film

AUDIO

• Intel® high-definition audio compliant
• Integrated speaker
• Keyboard volume and mute controls

KEYBOARD & INPUT

• 85-key with dedicated Windows® key
• Capacitor-sensitive touchpad

EXPANSION SLOTS

• PC card type II x 1
• SD card

INTERFACE

• HDMI Type A
• VGA D-sub 15-pin
• Headphones Mini-jack stereo
• Microphone Mini-jack stereo
• Serial D-sub 9-pin(x1)(RS232)
• Serial D-sub 9-pin (x 2)(RS232/RS422/RS485 MCU Configure)
• USB 2.0 (x 3) Type A
• 10/100/1000 Ethernet RJ-45 (x 2)
  Optional:USB3.0X2/LPT

WIRELESS

• 802.11a/b/g/n/ac
• Bluetooth® v4.0 + EDR (Class 1)

POWER SUPPLY

• Battery operation: 8hours
• Long life Li-Ion battery pack (11.1V, typical 6800mAh, 75.5Wh)
• Battery charge time: 3.5 hours on/off
• AC Adapter: AC 100V-240V 50/60Hz, DC 19V 3.42A

POWER MANAGEMENT

• Suspend/Resume Function, Hibernation, Standby, ACPI BIOS

SECURITY FEATURES

• Password Security: Supervisor, User, Hard Disk Lock
• Kensington cable lock slot

WARRANTY

• 3-year limited warranty, parts and labor

DIMENSIONS & WEIGHT

• 330mm(L) x 250mm(W) x 50mm(H)
• 3.9Kg

ENVIRONMENTAL

• Operating Temperature:: -20ºC to 55ºC(optional: -40ºC to 60ºC)
• Storage Temperature: -40ºC to 65ºC
• Humidity: 5% to 95% RH, Non-Condensing

INTEGRATED OPTIONS

• 256GB solid state drives (SSD)
